La solución de radiador atractiva, especial para la gama de baja temperatura. Zehnder Nova Neo responde a todas las exigencias. En comparación con un suelo radiante o un radiador convencional, el radiador de baja temperatura tiene una fase de calentamiento significativamente más corta a la misma temperatura del sistema. Con los ventiladores integrados activados, Zehnder Nova Neo ofrece confort con mayor rapidez. Disponible en numerosos colores y superficies de la carta de colores de Zehnder.
Energéticamente eficiente, ya que es apto para el funcionamiento con bomba de calor o sistema de baja temperatura
Ventiladores silenciosos integrados con regulación de tres niveles fáciles de usar para una fase de calentamiento considerablemente más corta y más potencia, confort y bienestar
Filtro de polvo integrado para una mejor higiene del aire
Montaje sencillo con placa de pared (no visible desde delante)
El mínimo tiempo de reacción permite un rápido calentamiento de los espacios
Alta potencia térmica que permite calentar grandes espacios
Las rejillas de protección aportan seguridad y transmiten una imagen elegante
| Modelos horizontales | ||||||
|---|---|---|---|---|---|---|
| Modelo | H | L | T | Potencia calorífica | ||
| 75/65/20 °C | 70/55/20 °C | 55/45/20 °C | ||||
| mm | mm | mm | W | W | W | |
| VRX-037-070/BF | 370 | 700 | 117 | 1042 | 880 | 613 |
| VRX-037-070/BP | 370 | 700 | 117 | 1042 | 880 | 613 |
| VRX-037-070/BS | 370 | 700 | 117 | 1042 | 880 | 613 |
| VRX-037-080/BF | 370 | 800 | 117 | 1191 | 1006 | 700 |
| VRX-037-080/BP | 370 | 800 | 117 | 1191 | 1006 | 700 |
| VRX-037-080/BS | 370 | 800 | 117 | 1191 | 1006 | 700 |
| VRX-037-100/BF | 370 | 1000 | 117 | 1778 | 1514 | 1072 |
| VRX-037-100/BP | 370 | 1000 | 117 | 1778 | 1514 | 1072 |
| VRX-037-100/BS | 370 | 1000 | 117 | 1778 | 1514 | 1072 |
| VRX-037-110/BF | 370 | 1100 | 117 | 1956 | 1665 | 1180 |
| VRX-037-110/BP | 370 | 1100 | 117 | 1956 | 1665 | 1180 |
| VRX-037-110/BS | 370 | 1100 | 117 | 1956 | 1665 | 1180 |
| VRX-037-120/BF | 370 | 1200 | 117 | 2134 | 1817 | 1287 |
| VRX-037-120/BP | 370 | 1200 | 117 | 2134 | 1817 | 1287 |
| VRX-037-120/BS | 370 | 1200 | 117 | 2134 | 1817 | 1287 |
| VRX-037-140/BF | 370 | 1400 | 117 | 2611 | 2234 | 1599 |
| VRX-037-140/BP | 370 | 1400 | 117 | 2611 | 2234 | 1599 |
| VRX-037-140/BS | 370 | 1400 | 117 | 2611 | 2234 | 1599 |
| VRX-037-150/BF | 370 | 1500 | 117 | 2797 | 2393 | 1713 |
| VRX-037-150/BP | 370 | 1500 | 117 | 2797 | 2393 | 1713 |
| VRX-037-150/BS | 370 | 1500 | 117 | 2797 | 2393 | 1713 |
|
H = altura, L = longitud, T = profundidad 75/65/20 = Nominal heat output according to EN 442 at fan speed 2 (design speed) | ||||||
| Modelos horizontales | ||||||
|---|---|---|---|---|---|---|
| Modelo | H | L | T | Potencia calorífica | ||
| 75/65/20 °C | 70/55/20 °C | 55/45/20 °C | ||||
| mm | mm | mm | W | W | W | |
| VRX-044-070/BF | 444 | 700 | 117 | 1087 | 916 | 636 |
| VRX-044-070/BP | 444 | 700 | 117 | 1087 | 916 | 636 |
| VRX-044-070/BS | 444 | 700 | 117 | 1087 | 916 | 636 |
| VRX-044-080/BF | 444 | 800 | 117 | 1243 | 1048 | 727 |
| VRX-044-080/BP | 444 | 800 | 117 | 1243 | 1048 | 727 |
| VRX-044-080/BS | 444 | 800 | 117 | 1243 | 1048 | 727 |
| VRX-044-100/BF | 444 | 1000 | 117 | 1855 | 1574 | 1107 |
| VRX-044-100/BP | 444 | 1000 | 117 | 1855 | 1574 | 1107 |
| VRX-044-100/BS | 444 | 1000 | 117 | 1855 | 1574 | 1107 |
| VRX-044-110/BF | 444 | 1100 | 117 | 2041 | 1732 | 1218 |
| VRX-044-110/BP | 444 | 1100 | 117 | 2041 | 1732 | 1218 |
| VRX-044-110/BS | 444 | 1100 | 117 | 2041 | 1732 | 1218 |
| VRX-044-120/BF | 444 | 1200 | 117 | 2227 | 1890 | 1329 |
| VRX-044-120/BP | 444 | 1200 | 117 | 2227 | 1890 | 1329 |
| VRX-044-120/BS | 444 | 1200 | 117 | 2227 | 1890 | 1329 |
| VRX-044-140/BF | 444 | 1400 | 117 | 2724 | 2327 | 1660 |
| VRX-044-140/BP | 444 | 1400 | 117 | 2724 | 2327 | 1660 |
| VRX-044-140/BS | 444 | 1400 | 117 | 2724 | 2327 | 1660 |
| VRX-044-150/BF | 444 | 1500 | 117 | 2919 | 2493 | 1778 |
| VRX-044-150/BP | 444 | 1500 | 117 | 2919 | 2493 | 1778 |
| VRX-044-150/BS | 444 | 1500 | 117 | 2919 | 2493 | 1778 |
|
H = altura, L = longitud, T = profundidad 75/65/20 = Nominal heat output according to EN 442 at fan speed 2 (design speed) | ||||||
| Modelos horizontales | ||||||
|---|---|---|---|---|---|---|
| Modelo | H | L | T | Potencia calorífica | ||
| 75/65/20 °C | 70/55/20 °C | 55/45/20 °C | ||||
| mm | mm | mm | W | W | W | |
| VRX-051-070/BF | 518 | 700 | 117 | 1135 | 954 | 657 |
| VRX-051-070/BP | 518 | 700 | 117 | 1135 | 954 | 657 |
| VRX-051-070/BS | 518 | 700 | 117 | 1135 | 954 | 657 |
| VRX-051-080/BF | 518 | 800 | 117 | 1297 | 1090 | 751 |
| VRX-051-080/BP | 518 | 800 | 117 | 1297 | 1090 | 751 |
| VRX-051-080/BS | 518 | 800 | 117 | 1297 | 1090 | 751 |
| VRX-051-100/BF | 518 | 1000 | 117 | 1936 | 1640 | 1150 |
| VRX-051-100/BP | 518 | 1000 | 117 | 1936 | 1640 | 1150 |
| VRX-051-100/BS | 518 | 1000 | 117 | 1936 | 1640 | 1150 |
| VRX-051-110/BF | 518 | 1100 | 117 | 2130 | 1805 | 1265 |
| VRX-051-110/BP | 518 | 1100 | 117 | 2130 | 1805 | 1265 |
| VRX-051-110/BS | 518 | 1100 | 117 | 2130 | 1805 | 1265 |
| VRX-051-120/BF | 518 | 1200 | 117 | 2323 | 1968 | 1380 |
| VRX-051-120/BP | 518 | 1200 | 117 | 2323 | 1968 | 1380 |
| VRX-051-120/BS | 518 | 1200 | 117 | 2323 | 1968 | 1380 |
| VRX-051-140/BF | 518 | 1400 | 117 | 2842 | 2420 | 1714 |
| VRX-051-140/BP | 518 | 1400 | 117 | 2842 | 2420 | 1714 |
| VRX-051-140/BS | 518 | 1400 | 117 | 2842 | 2420 | 1714 |
| VRX-051-150/BF | 518 | 1500 | 117 | 3045 | 2592 | 1836 |
| VRX-051-150/BP | 518 | 1500 | 117 | 3045 | 2592 | 1836 |
| VRX-051-150/BS | 518 | 1500 | 117 | 3045 | 2592 | 1836 |
|
H = altura, L = longitud, T = profundidad 75/65/20 = Nominal heat output according to EN 442 at fan speed 2 (design speed) | ||||||
| Modelos horizontales | ||||||
|---|---|---|---|---|---|---|
| Modelo | H | L | T | Potencia calorífica | ||
| 75/65/20 °C | 70/55/20 °C | 55/45/20 °C | ||||
| mm | mm | mm | W | W | W | |
| VRX-059-070/BF | 592 | 700 | 117 | 1184 | 993 | 682 |
| VRX-059-070/BP | 592 | 700 | 117 | 1184 | 993 | 682 |
| VRX-059-070/BS | 592 | 700 | 117 | 1184 | 993 | 682 |
| VRX-059-080/BF | 592 | 800 | 117 | 1353 | 1135 | 779 |
| VRX-059-080/BP | 592 | 800 | 117 | 1353 | 1135 | 779 |
| VRX-059-080/BS | 592 | 800 | 117 | 1353 | 1135 | 779 |
| VRX-059-100/BF | 592 | 1000 | 117 | 2020 | 1709 | 1194 |
| VRX-059-100/BP | 592 | 1000 | 117 | 2020 | 1709 | 1194 |
| VRX-059-100/BS | 592 | 1000 | 117 | 2020 | 1709 | 1194 |
| VRX-059-110/BF | 592 | 1100 | 117 | 2222 | 1880 | 1313 |
| VRX-059-110/BP | 592 | 1100 | 117 | 2222 | 1880 | 1313 |
| VRX-059-110/BS | 592 | 1100 | 117 | 2222 | 1880 | 1313 |
| VRX-059-120/BF | 592 | 1200 | 117 | 2424 | 2050 | 1432 |
| VRX-059-120/BP | 592 | 1200 | 117 | 2424 | 2050 | 1432 |
| VRX-059-120/BS | 592 | 1200 | 117 | 2424 | 2050 | 1432 |
| VRX-059-140/BF | 592 | 1400 | 117 | 2966 | 2521 | 1780 |
| VRX-059-140/BP | 592 | 1400 | 117 | 2966 | 2521 | 1780 |
| VRX-059-140/BS | 592 | 1400 | 117 | 2966 | 2521 | 1780 |
| VRX-059-150/BF | 592 | 1500 | 117 | 3178 | 2701 | 1907 |
| VRX-059-150/BP | 592 | 1500 | 117 | 3178 | 2701 | 1907 |
| VRX-059-150/BS | 592 | 1500 | 117 | 3178 | 2701 | 1907 |
|
H = altura, L = longitud, T = profundidad 75/65/20 = Nominal heat output according to EN 442 at fan speed 2 (design speed) | ||||||
| Modelos verticales | ||||||
|---|---|---|---|---|---|---|
| Modelo | H | L | T | Potencia calorífica | ||
| 75/65/20 °C | 70/55/20 °C | 55/45/20 °C | ||||
| mm | mm | mm | W | W | ||
| VRV-150-059/BP | 1500 | 592 | 115 | 2305 | 1966 | 1397 |
| VRV-150-059/BS | 1500 | 592 | 115 | 2305 | 1966 | 1397 |
| VRV-150-074/BP | 1500 | 740 | 115 | 2427 | 2063 | 1456 |
| VRV-150-074/BS | 1500 | 740 | 115 | 2427 | 2063 | 1456 |
| VRV-180-059/BF | 1800 | 592 | 115 | 2955 | 2520 | 1791 |
| VRV-180-059/BP | 1800 | 592 | 115 | 2955 | 2520 | 1791 |
| VRV-180-059/BS | 1800 | 592 | 115 | 2955 | 2520 | 1791 |
| VRV-180-074/BF | 1800 | 740 | 115 | 3070 | 2618 | 1861 |
| VRV-180-074/BP | 1800 | 740 | 115 | 3070 | 2618 | 1861 |
| VRV-180-074/BS | 1800 | 740 | 115 | 3070 | 2618 | 1861 |
| VRV-200-059/BF | 2000 | 592 | 115 | 3314 | 2835 | 2029 |
| VRV-200-059/BP | 2000 | 592 | 115 | 3314 | 2835 | 2029 |
| VRV-200-059/BS | 2000 | 592 | 115 | 3314 | 2835 | 2029 |
| VRV-200-074/BF | 2000 | 740 | 115 | 3470 | 2959 | 2103 |
| VRV-200-074/BP | 2000 | 740 | 115 | 3470 | 2959 | 2103 |
| VRV-200-074/BS | 2000 | 740 | 115 | 3470 | 2959 | 2103 |
|
H = altura, L = longitud, T = profundidad 75/65/20 = Nominal heat output according to EN 442 at fan speed 2 (design speed) | ||||||
